4 DLT ENGINE
R
emove drive shaft spigot bearing from crank shaft
using puller, 2654 5890 03 06. Refer figure 54.
U
nscrew banjo bolt and remove assembly piston
cooling nozzles.
CYLINDER HEAD DISMANTLING
R
emove
- Glow plugs. Refer figure 55.
- Injector over flow hoses.
- Injectors with flame guard, flame guard
washer and sealing washer. Refer figure 56.
Fig. 54
Fig. 55
Fig. 56
