SAFARI

486 PL ENGINE

Install special tool (Pt No. 2699 5890 0602) at spark

plug locating threads. Fig. 74

Press cam shafts with the tool. Fig. 75

Loosen mounting bolts of hydraulic cam chain

tensioner. Fig. 76

Unscrew cam shaft bearing cap nuts.

(Loosen first the extreme caps, then move towards

centre ones.) Fig. 77

Remove all bearing caps.

Fig.77

Fig. 75

Fig. 74

Fig. 76
