1518 / 1525
30
BODY
A
B
1
2
3
4
5
7
8
9
10
4
5
3
7
8
11
1.
HEXBOLTM12X95
2.
WASHER
3.
RUBBER MOUNTING (TOP)
4.
SPACER
5.
RUBBERMOUNTING (BOTTOM)
6.
WASHER
7.
BRIGHT WASHER 13
8.
SPRING WASHER B12
9.
NYLOC NUTM12
10. HEX NUTM12
11. BOLT
Fig. 28.
C
D
F
F
D
C
B
A
A
B
C
D
F (RH SIDE)
E (LH SIDE)
(510)
(570)
(1540)
(1215)
(2650)
(2032)
(3230)
(570)
(620)
(595)
H
G
(540)
(637)
RUBBER SUPPORT
AT LOCATION 'H'
RUBBER PAD
AT LOCATION 'G'
MOUNTING AT
LOCATION 'A, B, C, D & E'
MOUNTING AT
LOCATION 'F'
OF F. A.
OF VEHICLE
VEHICLE FRONT
6
6
23. BODY MOUNTING LOCATIONS
