ENGINE
106
CRANKSHAFT BEARING AND PARENT BORE
Engine No. ............................................................
Chassis No. ...........................................................
Kilometres .............................................................
Kilometres since last overhaul ..................................
Reason for dismantling................................................
....................................................................................
....................................................................................
....................................................................................
Measurement with Bearing Shells:
Dial Gauge set at............mm
Measuring Direction
Crank Shaft Bearing No.
1
2
3
4
5
A
mm
B
mm
C
mm
OVALITY
mm
Measurement with Bearing Shells:
Dial Gauge set at............mm
Parent Bore No.
Conclusions/Recommendations:
WITH BEARING SHELL
WITHOUT BEARING SHELL
Checked by.............................
Date .........................................
ENGINE INSPECTION SHEET II
1
2
3
4
5
A
mm
B
mm
C
mm
OVALITY
mm
