ENGINE2.2LDICOR
l
Disconnect EGR pipe connected between EGR
valve and exhaust manifold. (Fig.12 & 13)
Fig. 11
Fig.12
Fig.10
Remove the HP pipe connected between the
common rail & HP pump. (Fig.10 & Fig.11) Cover
the openings with Suitable caps.
