ENGINE2.2LDICOR
A.CCOMPRESSORBELT
Fig. 1
Fig. 2
Fig. 3
Removal
Remove AC Compressor belt tensioner cap and
loosen the tensioner nut. (Fig. 1)
Relieve AC Compressor belt tension by rotating
the tensioner screw in clock wise direction.
(Fig. 2)
Remove the belt. (Fig. 3)
