SAFARI

FRONT AXLE - 4

Make sure that the free - running hub is installed

correctly by pushing it lightly by hand. If there is

some clearance between wheel hub and free -

running hub housing, reinstall it.

Fig.6

After free - running hub is installed correctly, tighten

bolts to specified torque.

After installation, set knobs on both sides to Auto,

then release hub from Lock position by moving loaded

wheels forward and backward when drive shafts are

stationery.

Fig. 7

The reason for above maneuver is that the difference

in the lock and free position from other side which

might cause differential carrier gear noise.

Fig. 6

Fig. 7

LOCK

AUTO

LOCK

AUTO
