ELECTRICALS
17
Fig. 16 Adjusting Head Lamp Focus with the Help of Screen
C/LOFVEH.
TATASAFARIHEADLAMPSETTINGSCREEN(LHTRAFFIC)AT10m(10,000mm)FROM
HEADLAMP.
BULBCENTREPROJECTEDONTHESCREEN
C/LOFRHHEADLAMP
C/LOFLHHEADLAMP
Y=-578
Y=578
ROADLEVEL
Y=0
CUT OFF LINE
BREAKING POINT
DIRECTION OF THE TRAVEL
CENTRE MARK
TEST SCREEN
SCREEN SETTING LAYOUT
ROAD
q
q
OF HEADLAMP
LH SIDE
q
OF HEADLAMP
RH SIDE
HEADLAMPLHS
HEADLAMP
RHS
100
HEAD LAMP SETTING PROCEDURE (RHD)
1800
(Min)
1800
(Min)
15°
600
100
851
(UNLADEN)
600
1156
10000
90°
q
OF VEHICLE
881 mm
