1307 / 1588
ENGINE
108
Engine No. ..........................................................
Chassis No. .........................................................
Kilometres ...........................................................
Kilometres since last overhaul ................................
Reason for dismantling ..........................................
.........................................................................
....................................................................................
....................................................................................
DIESELVEHICLES
CONNECTING ROD BEARING AND PARENT BORES
SHEET IV
MEASURING
BIG END BEARING BORE DIA. (WITH SHELLS INSTALLED) GAUGE SET AT.................mm
DIRECTION
1
2
3
4
A
mm
B
mm
C
mm
OVALITY
mm
WEIGHT GROUP
COLOUR MARKS
SMALL END:
BIG END:
A
mm
B
mm
C
mm
OVALITY
mm
A
mm
B
mm
OVALITY
mm
TWIST
BEND
Conclusions/Recommendations:
Checked by......................................
Date ................................................
ENGINE INSPECTION SHEET
182.05 mm
182.00 mm
Without bearing shell
MEASURING
CONNECTING BIG END PARENT BORE GAUGE AT............................mm
DIRECTION
1
2
3
4
CONNECTING BIG END PARENT BORE GAUGE AT............................mm
1
2
3
4
ALIGNMENT
1
2
3
4
