DRIVETRAIN-TA65 Star
42
12. Unstake and unlock the locknut on Input
shaft.
13. Removelock plate (5th speed gear).
14. Remove engaging gear (5th speed) along
with sleeve and fork taking care that carrier
assembly does not slip off.
15. Remove the fifth gear from the lay shaft.
16. Remove needle bearing
17. Remove the bush.
18. Remove spacer (lay shaft).
19. Remove the conical washer and 5th gear
(input shaft).
20. Remove lock plate (lay shaft bearing) from
housing rear half by unscrewing T40 torx
head screws
21. (Use new torx head screws during
reassembly).
