DRIVETRAIN-TA65 Star
40
24. Remove clutch release bearing from input
shaft.
25. Lift and support the engine assembly properly
using engine holding stand (2871 5890 3211)
on vehicle.
5.7. F. TRANSAXLE TA65 STAR (ON BENCH)
DISASSEMBLY:
1. Ensure that oil is drained completely from the
transaxle before mounting on the work stand.
2. Fix the mounting plate (2702 5890 2610) on
work stand 2573 5890 3701 (19a) by using
hex bolt in 3 holes of 14mm dia. on the
mounting plate.
3. Mount transaxle face on mounting plate and fix
it by three hex bolts of M10 size and remove
assembly reverse light switch. Remove the ‘B’
mount bracket if required.
