315 / 1235
GEAR BOX
46
F.TOP COVER
1. Remove pin cross gate limiter (1) which is for
shifter assembly, Captive detent for selection (2)
and captive detent for shifter (3) from the top
cover assembly.
2. Remove the plug using Allen key.
3. Remove spiral pin by pushing it outwards from
the selector shaft.
4. Support the swing blocker along with the selector
finger and push out the selector shaft.
NOTE
Remove the oil seal from the top cover housing and
dispose the same.
