778 / 1428
808
BODY
FLOOR CARPET
Removal
1. Remove three screws securing side panel to the
driver’s seat. (Repeat same procedure for co-driver
side)
2. Remove two bolts securing seat mounting bracket
to the body.
3. Remove the centre bolt securing seat mounting
bracket to the body.
Installation
1. Fix roof trim on to the roof using the adhesive
(Headliner adhesive WC - 2446)
2. Fit all tree clips on to the roof trim.
3. Connect the electrical connector of roof mounted
stop lamp and fit stop lamp.
4. Fit reading lamp and both sun visors.
6. Remove six tree clips and take out roof trim .
7. Take out roof trim
