Installation
1. Carefully insert and slide the window glass inside
glass run mould (GRM) to ensure its free
movement.
2. Tighten two mounting screws.
3. Fit door pad. (Refer front door pad installation
procedure)
4. Fix door plastic membrane.
4. For power window, removewindow regulatingmotor
as follows :
(a) Disconnect the electrical connector of power
window regulating motor.
(b) Remove three bolts securing window regulating
motor to the bracket of window winding
mechanism.
FRONT WINDOW WINDING MECHANISM
Removal
1. Remove door pad. (Refer front door pad removal
procedure)
2. Remove door window glass. (Refer front door
window glass removal procedure)
3. Remove all bolts and take out window winding
mechanism.
