549 / 1428
BRAKE SYSTEM
537
BRAKES
3. Remove the rubber grommets (08) from the TMC
inlet ports as shown.
4. Remove the TMC boot (09)
5. By depressing the primary piston with attached
push rod, remove Secondary piston stopper (07).
6. By depressing the primary piston with attached
push rod, remove circlip (11) with circlip pliers.
7. Remove push rod assembly.
8. Remove primary piston assembly (05)
