ENGINE 273 MPFI
181
ENGINE
A - Engine Oil filling Cap
B - Dip Stick
SYSTEM MAINTENANCE
Engine Oil Replacement
Inspection:
Before draining engine oil, check engine for any oil
leakage. If any leakage is found make a note of it and
repair or replace the defective part before refilling the
engine oil.
Engine Oil Drain Procedure
•
Position the car on a two post lift.
•
Open the Engine Oil filling Cap.
•
Position a suitable container for collecting the
drained Engine oil below the oil sump drain plug.
•
Loosen and remove oil sump drain plug with the
help of socket spanner.
•
Drain Engine oil in the container placed below the
drain plug.
•
After draining the oil completely, wipe the drain plug
and reinstall the drain plug.
CAUTION
Contaminated and used engine oil can be
hazardous.
This activity should be performedwith ENGINENOT
RUNNING.
Use recommended Grade of Oil only.
Replace the engine oil at recommended interval
specified in service schedule to ensure long life of
engine.
NOTE
When replacing the Engine Oil, allow the oil to drain
completely and then refill it with new oil through oil
filling cap after ensuring that drain plug is
reinstalled.
Ensure that proper quantity of oil is refilled
according to Oil Dipstick marking.
Dispose the used oil in environment friendlymanner.
Follow all governing regulations for proper disposal
of these materials.
Engine Oil Level Checking
Engine oil level should be checked when engine is
cold. Allow at least 30 mins. for engine oil to settle
before checking oil level.
1. For checking engine oil level, pull out the dipstick
from the engine oil case, wipe it clean with a cloth
or a paper napkin.
2. Insert it again to its original position.
3. Pull out the dipstick again and observe the oil level
on the dipstick.
4. If the oil level is below the mid point of min. and
max. marks, top up using recommended grade of
oil.
NOTICE
Oil level should not exceed the max. Mark. Always
check the oil level when the car is on a level ground
and the engine in cold condition.
Check the engine oil level if “low oil pressure” warning
comes 'ON' while driving. Failure to check the oil level
regularly could lead toserious troubledue to insufficient
oil.
Engine oil top-up
Remove the oil filler cap and pour oil slowly through
the filler hole to bring the oil level to the upper limit on
the dipstick. Be careful not to overfill. Too much oil is
almost as bad as too little oil. After refilling, start the
engine and allow it to idle for about a minute. Stop the
engine; let the oil settle and check oil level again.
