ENGINE 273 MPFI
157
ENGINE
SYSTEM MAINTENANCE
Replacement of Accelerator Cable
•
Remove rear seat completely from vehicle. (Refer
Removal procedure of Rear Seat fromBody group)
•
Take out engine access cover with the help of screw
driver.
NOTE
Six notch locks are provided on insulation engine
cover. Insert the screw driver at any notch position
to facilitate easy removal of cover from body.
•
Loosen the nut at the throttle body
•
Remove the cable from the bracket.
•
Remove cable terminal from the throttle body.
NOTE
Make sure not to damage the rubber dust cap.
•
Cut cable tie from engine cradle.
•
Remove all clamps for accelerator cable.
•
Remove clamp from cross member front
•
Release the cable terminal (pedal side) from
accelerator pedal slot.
•
Press the floor end fitting & push it back out of
firewall to take the cable out.
•
Pull the cable out from underbody from the area
near wheel arch.
