DRIVETRAIN
50
5. Invert the assembly and insert the circlip on the
groove using a circlip plier.
6. Insert the spacer.
7. Insert the reverse gear spring (02) to rest on the
spacer (03) and then insert the circlip (01).
8. Place the cup and press and hold it down.
9 Holding the cap down place the top cover plate
and tighten the four M6 bolts to a torque of 0.85
~ 1.25 kgm.
10 Place the spacer and fit the spiral pin
