1126 / 1428
ENGINE
7
5. REMOVAL AND REFITMENT OF ENGINE
ACCESS WINDOW AND ENGINE COVER
A. ENGINE ACCESS WINDOW
Removal:
NOTE:
Park the vehicle with brakes ON and duel
selector switch is kept in CNG mode.
Manually turn of the tank valve and connect
the TML tester tool and start the service
“Empty CNG lines”
Crank the engine and run in idle condition
until engine stop at its own.
Re crank the engine it should not start (tank
pressure should be 0 bar)
WARNING :
Do not turn OFF Cylinder Valves , in vehicle
running in CNG mode. This may wrongly
detect the leakage error.
Pull the strip which is located left side behind the
upper part of rear seat.
Fold the upper part of rear seat
Remove the mounting bolt of upper rear seat to
body.
Remove the two mounting bolts located bottom
of lower rear seat.
