4. Remove the bolt located near parking brake lever

and between two seats.

5. Remove the bolt securing seat mounting bracket

to the body (co-driver side)

6. Remove B-pillar trim. (Refer B- pillar trim removal

procedure)

7. Remove the bolt securing seat mounting bracket

to the body and take out front seats along with

seat mounting bracket.

8. Remove centre console. (Refer Centre Console

removal procedure)

9. Remove omega clips securing gear shifter and

selector cables.

10.Disengage gear shifter and selector cables from

gear shifter lever.
