NANO

ELECTRICAL

639

ELECTRICAL

11) Remove the Yoke and Armature assembly from

the Annulus and Fixing Bracket assembly.

12) Hold the Yoke assembly in a vice and then pull

the Armature assembly.

10) Remove Brush Gear assembly from the

armature assembly.

13) Separate the Armature assembly from the Yoke

assembly.

14) Remove the Packing from theAnnulus.

15) Remove the Grommet and Pivot plate from fixing

bracket assembly.
