NANO

624

ELECTRICAL

6) Smoothly roll over the rivet 4 nos.

5) Insert the Retainer into the DE Bracket assembly.

3) Place the Rivet in position.

4) Turn around the DE Bracket with base tool.

2) Insert the 4 nos. rivet into the DE Bracket assembly.

13. RE-ASSEMBLY

It is reverse order of dismantling procedure. Note the

following precautions.

1) Fix the DE Ball Bearing into the DE Bracket

assembly.
