STEERING SYSTEM

569

STEERING

SCHEMATIC OF STEERING SYSTEM

. DESCRIPTION

1 Steering wheel

2 Steering upper column

3 Upper universal joint

4 Intermediate shaft

5 Lower universal joint or Steering gear end

universal joint

6 Steering rack and pinion assembly

7 Tie rod assembly

8 Outer ball joints
