343 / 1980
DRIVETRAIN
337
DRIVETRAIN
3. Place the upper bush (3) with little amount of grease
on it so that the bush holds the clutch release yoke
(2) into its position.
4. Now lock the internal return spring (4) with the front
half housing.
2. Now put the clutch release yoke (2) into the inner
bush.
6. Place the external return spring.
5. Place the clutch release bearing (5) on the shaft
and smear some grease on it. Also apply grease
at the point of contact between the bearing and
the yoke.
