HVAC
893
HVAC
REFRIGERANT LINES / AC PIPE LINES
Sr.No. Description
Assembly Pipe - Suction
01 Suction Pipe Part 1
02 Suction Pipe Part 2
03 Suction Pipe Part 3
04 Suction Pipe Part 4
05 O-Ring
06 O-Ring
Sr.No. Description
Assembly Pipe - Discharge
07 Discharge Pipe Part 1
08 Discharge Pipe Part 2
09 Discharge Pipe Part 3
10 Discharge Pipe Part 4
11 O-Ring
12 O-Ring
13 Liquid Pipe Assembly
14 O - Ring
15 Pressure Switch
16 Hex. Bolt
17 Hex. Bolt
18 Hex. Bolt
