DRIVETRAIN
321
DRIVETRAIN
NOTE : Tighten clutch release lever nut with 1.7 -1.9 kg-m with thread locking adhesive Anabond 112
SR.NO DESCRIPTION
01 CLUTCH DISC & PRESSURE PLATE
02 CLUTCHCOVER
03 CLUTCHDISC
04 ASSY CLUTCH RELEASE BEARING
05 BUSH LOWER (ON HOUSING)
06 ASSY CLUTCH RELEASE YOKE
07 RETURNSPRING (INTERNAL)
08 UPPER BUSH (ON HOUSING)
09 RETURNSPRING (EXTERNAL)
10 CLUTCH RELEASE LEVER
11 HEX FL BOLTM8X35
12 HEX FLNUTAM8
13 HEX FL BOLTM8X40
14 ASSY BACKCOVERWITH FOAM STRIP
15 HEX FL BOLTM6X30
16 SPRINGWASHER
17 SET SCREW
