169 / 896
ENGINE COOLING COMPONENTS
13
6. Connect both inlet and outlet radiator hoses
clamps.
7. Install the condensor assembly carefully.
8. Tighten condenser bolts mounted on the both
side of the body as per the specified torque.
(8 Nm)
9. Tighten the clamp bolt for radiator and
condenser hoses as per the specified torque.
(9 Nm)
10. Connect high and low side refrigerant hose
and tighten their bolts as per the specified
torque. (8 Nm)
NOTE
Replace ‘O-rings’ of high and low side
refrigerant hoses if necessary to avoid leakage.
11. Tighten the drain plug.
