ELECTRICAL

FUSE BOX AND RELAY ( BATTERY MOUNTED )

1

100A

CAL 1

STARTER

2

100A

3

ALTERNATOR

FROM MAIN WH

FROM BATT +VE CABLE

FROM BATT +VE CABLE
