BODY
4. Remove pop up knob by rotating the knob.
REAR LATCH ASSEMBLY
Removal
1. Remove door pad. (Refer Rear door pad removal
procedure)
2. Remove door window glass. (Refer Rear door
window glass removal procedure)
3. Remove three screws securing latch to the body.
REAR WINDOW WINDING MECHANISM
Removal
1. Remove door pad. (Refer Rear door pad removal
procedure)
2. Remove door window glass. (Refer Rear door
window glass removal procedure)
3. Remove four bolts and take out window winding
mechanism.
Installation
1. Tighten four bolts and fix window winding
mechanism.
2. Fit door window glass. (Refer Rear door window
glass installation procedure)
3. Fit door pad. (Refer Rear door pad installation
procedure)
5. Disengage following linkages.
(a) Attached from door inner handle to latch
(b) Attached from outer handle to latch.
