NANO

BODY

799

BODY

Installation

1. Tighten two bolts and fit seat cushion into hooks.

2. Tighten four bolts and fit seat back.

3. Push back the seat in normal position.

Removal

NOTE :

Rear seat comes in two parts i.e. seat cushion part

and seat back part.

Removal

1. Pull the strip (located behind the rear seat) up in

the arrow direction to unfold the seat. (Repeat

same procedure for other side)

2. Remove four bolts securing seat back to the body

and take out seat back.

3. Remove two bolts securing seat cushion to the

body.

4. Remove the seat cushion from the hooks and take

out seat cushion.
