2. Remove the lock ring of window winding handle

and take out the handle.

3. Remove two screws of door pull handle.

4. Pry out the door pad with the help of plastic wedge.

(Part. No. 2871 5890 40 02) and pull out door pad.

Installation

1. Replace the damaged grommets.

2. Align the door pad on door pad grommet holes.

3. Press the door pad such that all grommets seats

properly.

For Luxury Version

4. Tighten the screws of door pull handle and door

inner handle

5. Fix the lock ring and fit window winding handle.

For Deluxe and Standard Version

6. Tighten the screw of door inner handle and door

cup.

7. Fix the lock ring and fit window winding handle.
