DRIVETRAIN
6
Front half to rear half
M8 Bolts
2.1 ~ 2.5
fastening (on rear half).
(13 Nos.)
7
Front half to rear half
M8 bolts
2.1 ~ 2.5
fastening (on front half).
(2 Nos.)
8
Oil collector mounting
M6 Bolt
0.4 ~ 0.45
on front half
(1 No)
9
Rear cover fastening
M8 Bolts
2.1 ~ 2.5
bolts.
(6 Nos. )
10 Reverse gear shifter
M8 Bolts
2.1 ~ 2.5
gear fastening to front
(2 Nos.)
half housing.
SL NO DESCRIPTION
FASTENER
TORQUE
LOCATION
TYPE / QTY
(Kg–m)
