ENGINE 273 MPFI
183
ENGINE
OIL PRESSURE SWITCH
(Refer Electrical Group)
Water & Oil Pump Assembly
Removal Procedure:
•
Position the car on a two post lift.
•
Drain Engine Coolant. (Refer Engine Coolant Drain
procedure)
•
Drain oil from oil sump (Refer Engine Oil Drain
procedure)
•
Remove cylinder head cover & lock the camshaft
using special tool (Part No.2834 5890 06 20).
•
Lock the flywheel using special tool ( Part No.2834
5890 06 14).
•
Loosen the alternator upper mounting bolt and
remove belt .
•
Loosen the compressor upper mounting bolt and
disengage the compressor belt.
•
Declamp harness from timing cover.
