NANO

BODY

BULB REPLACEMENT PROCEDURE

1. Remove front bumper.

2. Disconnect electrical connection of fog lamp.

3. Remove the bulb assembly by rotating in anti-

clockwise direction.

4. Take out the bulb from holder and replace with

new one.

5. Fit the bulb assembly by rotating in clockwise

direction.

6. Connect the electrical connection.

7. Fit the front bumper.

1.7 LIGHT STALK REMOVAL AND REFITMENT

NOTE

Lighting stalk and wiper stalk removal and there

refitment is identical. Hence only lighting stalk re-

moval and refitment is demonstrated below

REMOVAL

1. Remove steering wheel.

2. Remove two screws securing steering column

upper panel to the lower panel.
