NANO

ELECTRICAL

2.3.EPAS ECU:

2.3.1. SPECIFICATION

Max. Current

43.5A

Static Condition ( No torque input on steering wheel)

300mA

Inrush Current

10A

Stall current

24.5A

Operating Temperature

-40°C to +80°C (Ambient Temp)

Storage Temperature

-40°C to +90°C

2.3.2. LOCATION

It is fitted on mounting bracket on the steering column below dashboard assembly.
