ELECTRICALS
99
2.0 FOG LAMP REMOVAL AND RE-
FITMENT ON VEHICLE:-
Removal:
1. Open the front bonnet.
2. Turn the wheel to lock to lock position.
3. Remove all mounting screws of fender liners
from both side.
4. Remove the fender liners.
5. Remove all 8 mounting bolts securing front
bumper to the body.
6. Disconnect both fog lamp wiring harness
connectors from inner side of the bumper.
