ENGINE
77
Follow the following sequence for removing;
1
st
and 5
th
, 2
nd
and 4
th
and lastly 3
rd
.
25.Take out the Crankshaft from the cylinder block.
26.Remove Allen screws and take out all piston cool-
ing nozzles.
CRANKSHAFT SPIGOT BEARING
The crankshaft spigot bearing can be removed using
puller Part No. 2654 5890 03 06 (1) and the same
can be assemble using a suitable drift.
PISTON CONNECTING ROD DISASSEMBLY
1. Remove piston pin circlip with suitable plier
2. Remove piston pin from the piston by pushing it
out using a soft drift
