11.2.1 TIGHTENING TORQUES:
SR.NO.
LOCATION
DETAILS
TIGHTENING TORQUE
1
AT compressor end
M6 Nut
14 Nm ± 10%
2
TXV end
M6*16 CAP screw
10 Nm ± 10%
3
AT comp end
M6 Nut
14 m ± 10%
4
At cond end
M6 Nut
8 Nm ± 10%
5
HVAC unit fitment on CCB
M5 X 19 class 8.8
3 ± 1 Nm
6
HVAC control panel on Dashboard
ST 4.8 X 17
2 ± 0.3 Nm
7
Condenser fitment on Radiator
M6 x 16
4.5 ± 1 Nm
