AIR CONDITIONING
2
11.2 TECHNICAL SPECIFICATIONS:
IMPORTANT SPECIFICATION
Make
Model Applicability
Refrigerant
Refrigerant charge Quantity
Compressor Lube oil used
Compressor oil (total quantity)
Lubrication Oil to be topped up in the system in
case of replacing any of the following aggregates:
a.
Receiver Drier
b.
Condenser
c.
Evaporator
d.
All Pipes
System Pressure: Car in stationary condition with
engine speed at 1500 rpm.
Discharge Pressure
Suction Pressure
High - Low safety pressure switch
Medium pressure switch
HVAC SYSTEM
BEHR / SUBROS
HVAC
R-134a
1. 500 ± 20 gm (BEHR QUADRAJET)
2. 500 ± 20 gm (BEHR REVOTRON)
3. 500 ± 20 gm (SUBROS QUADRAJET)
4. 500 ± 20 gm (SUBROS REVOTRON)
FD 46XG (PAG) EQV ND - 8
1. 100 ± 15 cc (BEHR QUADRAJET)
2. 100 ± 15 cc (BEHR REVOTRON)
3. 100 ± 15 cc (SUBROS QUADRAJET)
4. 100 ± 15 cc (SUBROS REVOTRON)
20 ml
20 ml
20 ml.
10 ml. each
15 kg / cm2 to 28 kg / cm2
1.5 kg / cm2 to 3.5 kg / cm2
2 kg / cm2 to 32 kg / cm2
Cut off at 15.5 kg / cm2 Cut in at 20.5 kg / cm2
for two speed condenser fan
