SUSPENSION
15
CAUTION:
1. Ensure that brake hose does not damage
during installation.
2. Strut having the same color code mark on the
spring should be assembled on the left hand
and right hand side.
6.7.2 DISASSEMBLY AND ASSEMBLY OF
FRONT STRUT
DISASSEMBLY:
Compress the spring with spring Compression
tool part No.2702 5890 3202 until the spring
tension is released (i.e. becomes free in its
seating place).Hold the piston rod by Allen key
(A/F: 6 mm) to stop piston rod rotation during
loosening of nut. Unscrew nut (1) and dismantle
the parts.
