ELECTRICAL
154
3.5 REAR WASH CONTROL
3.5.1 Description
Rear Windshield provides vehicle user with Rear visibility directly or through the inside rear view
mirror. Rain and dirt on the rear windshield quickly turn the rear window into a risk on visibility and
safety. Hence, Rear wiper is needed to have a clear view outside at back of the vehicle. Rear
washer shall be controlled from Rear washer switch (rotary switch), located on the control lever.
3.5.2 Conditional Requirements
Activation –
• IGN is ON
• Rear Wash is activated
Deactivation –
• IGN is OFF or
• Rear Wash is deactivated or
• After pre configured wash wipes
On Fault –
Respective DTC logged
3.4.3 Operating Voltage Range
DESCRIPTION
REQUIREMENT
VOLTAGE
Rear Wash Control. Normal operating voltage range
9V-16V
3.4.4 Operating Temperature Range
DESCRIPTION
REQUIREMENT
VOLTAGE
Rear Wash Control.
Operating temperature range
-30
c to +85
c
Storage temperature range:
-40
c to +105
c
3.5.5 Inputs & Outputs
