ELECTRICAL
24
1.5 Display Messages for TFT Screen
The messages shall be displayed in the screen for 4 sec based on the priority and some of the warnings
shall be minimised in the screen
Warning (Shown With Red Border)
SN
Warning Title
Warning Message Title
Warning Messages on
Instrument Cluster
1
Fasten Seat Belt - Driver
Seat Belt Reminder
Fasten Driver Seat Belt
2
Speed Limit Warning
Speed Limit Warning
Over Speeding Detected Slow
Down
3
Transmission Failure Drive
Cautiously Visit Service Centre
Transmission Malfunction
Drive Cautiously Contact Service
Centre
4
Drive Control Shift Denied
Transmission Warning
Drive Control Shift Denied
5
Hill Hold Control Failure
Hill Hold Control
Malfunction Detected Contact
Service Centre
6
Hill Decent Control Failure
Hill Decent Control
Malfunction Detected Contact
Service Centre
7
Fuel Level Low State
Fuel Level Warning
Fuel Level Low
8
Fasten seat belt front passenger
Seat Belt Reminder
Fasten Co-driver Seat Belt
9
Transmission Failure Limp home
Activated Visit Service Centre
Transmission System
Malfunction Detected Contact
Service Centre
10 DEF level warning 1
DEF Level Low
DEF Level Low Refill Soon
11 DEF level warning 2
DEF Level Low
Engine Stops in “Value” Km Refill
DEF
12 DEF level warning 3
DEF Level Low
Engine Stops in “Value” Km
13 DEF level warning 4
DEF Level Low
Engine Stops in “Value” Km Refill
DEF
14 DEF level warning 5
DEF Level Low
Engine Stops in “Value” Km Refill
DEF
15 DEF level warning 6
DEF Level Low
Engine Will Not Restart In Next
Key On
16 DEF level warning 7
DEF Level Low
Engine Stop DEF Tank Empty
17 DEF quality warning 1
DEF Quality Low
DEF Quality Low
Check DEF System
18 DEF quality warning 2
DEF Quality Low
Engine Stops in “Value” Km
Check DEF System
