BODY

42

1.4.26 REAR SEAT BELT

REMOVAL

1. Remove parcel shelf.

2. Remove rear seat backrest (for removal

process refer rear seat removal process).

3. Flip the cushion assembly.

4. Remove rear seat belt bottom mounting

fastener.

5. Remove the bottom mounting fastener & C

pillar upper and lower trim. (For procedure

refer C pillar removal process.)

6. Remove two upper mounting bolts on C piller

BIW panel.

7. Loosen and remove the RPLL mounting bolt.

8. Remove centre seat belt mounting bolts shown

in figure.

9. Remove the rear seat belt assembly.

FITMENT

For fitment follow reverse procedure of removal.
