FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
1. Ensure proper tightening torque is given to
the hinges of tailgate. For torque value refer
to the tightening torque table.
2. If shim is damage please replace as per
below process.
3. Location Shim at Tailgate Inner Panel side to
control the Rattling of Tailgate.
4. Remove the shim mounting screw and
replace same procedure.
Tail gate Opening from cabin
1.
Sliding Direction.
TAIL GATE STRIKER
REMOVAL
1. Open the tailgate.
2. Loosen and remove two mounting screws.
3. Disconnect Tail gate latch cable and remove
the tail gate striker.
FITMENT
For fitment follow reverse procedure of removal.
