FATC
19
NOTE
1. The outside air intakes for the climate control
system are at the base of windscreen. Keep this
area clear from leaves and other debris.
2. The system should be used with recirculation
air mode for faster heat up and cool down,
however keeping the system in recirculation
mode, particularly with AC OFF, can cause the
windows fog up.
CAUTIONS
It is recommended to run the vehicle in re
circulation mode to avoid clogging of air filter.
10. AUTO MODE
During AUTO AC operation, the system automatically
cuts off compressor at a higher temperature than
normal AC. The operation can be used during mild
weather conditions for better fuel efficiency. Comfort
level may be compromised during this operation.
11. AUTO ON SELECTION BUTTON
In the AUTO mode all the configurable parameters
will be selected automatically except temperature
selection
To put the automatic climate control in fully
automatic mode:
a. Set the desired temperature by turning
temperature control knob.
b. Press the ‘AUTO’ button.
c. The system automatically selects the proper mix of
conditioned and/or heated air that will, as quickly
as possible, raise or lowers the interior
temperature to your preference.
You can manually select various functions of the
climate control system when it is in fully automatic
mode. Making any manual selection causes the
word ‘AUTO’ in the display to go OFF and
overridden setting is displayed.
12. TEMPERATURE CONTROL KNOB
Turning the temperature control knob clockwise
increases the temperature of the air. Steps of 0.5 º
C. will increase the desired temperature. User can
select temperature range from 18ºC to 30ºC.
Whereas the anti-clockwise direction decreases.
The desired temperature selected by the user shall
be updated in the display simultaneously as per the
rotation of the knob.
When you set the temperature to its lower limit (Lo)
or its upper limit (Hi), the system performs to provide
full cooling or heating respectively. It does not
regulate the interior temperature
