CLUTCH
7
10. ON VEHICLE PROCEDURES
A. SPECIAL TOOL ASSEMBLY:
The process to fix cover assembly on flywheel
has an impact on its functional characteristics.
In order to preserve the conformity, it is
necessary to apply counter force free process
(clutch to be assembled in clutch disengaged
condition) on clutch.
To maintain characteristics parameters
unchanged, it is necessary to impose the
bearing stroke and put the cover effortless in
contact with the flywheel, until gap between
cover and flywheel is closed.
For this process it is mandatory to use the tool
Part no. : 1871003100.
B. DISASSEMBLY PROCEDURE:
Remove transaxle (Refer transaxle removal
procedure).
Lock the flywheel.
Remove 3 alternate mounting bolts of Clutch
assembly for fitment of Clutch alignment
locking tool.
Fit the Clutch alignment locking tool on the on
the clutch assembly.
Introduce the strap part no. C0196010
between the screw and cliquet so as to avoid
the movement of adjustment device.
