P228006:- Self-test failure
Overview:
ISO Code (If applicable)
P228006
Customer Symptom
NA
Fault Effect (On Vehicle)
OBC will stop charging HV battery
Lamp Status (If Any)
NA
DTC Detection Condition
The charger is shut down and locked due a failed self-test.
Normal Operating Condition
Self-test success
Probable Trouble Area
OBC Self-test fail
Healing Condition
Disconnect the gun and connect back after VCU sleep
Write up for
the system:-
The on-board charger (OBC) takes AC input and converts it to direct current to charge a HV battery. The LV supply of OBC
is from 12V battery. It requires AC HV supply voltage of 230V, 50Hz to charge the HV battery.
.
Pre-Check Points:-
KL 30
12V LV supply to OBC
KL 31
LV/Chassis ground to OBC
a) Check for proper terminal connection of 12V LV Battery
b) Check for 12V LV Battery Voltage is with in the range ( 7.5V to 14V)
TroubleShooting:-
Flow Diagram or table format for diagnosing the fault code
Step no
.
Description
Check Point
if YES
if NO
1
Connect the Charging Gun & switch
ON the AC supply. check for the fault
code.
Fault code P228006, is
present?
Replace the OBC
Repair complete
On-Board charger
230V AC supply
HV Battery
LV signal connector
