P229300:- Low temperature shutdown
Overview:
ISO Code (If applicable)
P229300
Customer Symptom
NA
Fault Effect (On Vehicle)
OBC will stop charging HV battery
Lamp Status (If Any)
NA
DTC Detection Condition
Internal temperature of OBC less than -45
℃
Normal Operating Condition
Internal temperature of OBC higher than -45
℃
Probable Trouble Area
1. Temperature sensor failure in OBC.
2. Low coolant level.
Healing Condition
Disconnect the gun and connect back after VCU sleep
Write up for
the system:-
The On-Board Charger (OBC) takes AC input and converts it to direct current to charge a HV battery. The LV supply of OBC
is from 12V battery. It requires AC HV supply voltage of 230V, 50Hz to charge the HV battery. Without the LV supply
charging is not possible.
Pre-Check Points:
Pre-Check Points:
c) Check the coolant level
d) Check the coolant system proper connection and make sure there is no leakage
e)
Check for the LV connector pins for damage
TroubleShooting:-
Flow Diagram or table format for diagnosing the fault code
Step no
.
Description
Check Point
if YES
if NO
1
Connect the Charging Gun & switch
ON the AC supply. check for the fault
code.
Fault code P229300, is
present?
Replace the OBC
Repair complete
DTC
’
s
confirmation:-
After rectification, ensure the following points by referring OBC parameters using TML diagnostic tool before
handing over to customer.
a) Check whether the OBC can respond to the vehicle charging command by observing the Charge ON
indicator lamp on the cluster.
On-Board charger
230V AC supply
HV Battery
LV signal connector
