NEXON EV SERVICE MANUAL

NEXON EV

X114H

DTC Troubleshooting Data

Version: 3.0

Date: 27-May-2020

Author: K Tejaswini Manasa/ Navya Krishnan/Gaurav Jha

This document must not be used in anyway, such as copying and redistributing to third parties, without the consent of author.

P229003:- CP Test point Duty cycle out of range

Overview:

ISO Code (If applicable)

P229003

Customer Symptom

Fault Effect (On Vehicle)

OBC will stop charging HV battery

Lamp Status (If Any)

DTC Detection Condition

This DTC gets logged if CP test point Duty cycle < 7%

Normal Operating Condition

CP test point Duty cycle >7%

Probable Trouble Area

1. Incorrect CP duty cycle from Charging Gun.

2. Trigger circuit in Charging Gun is failed.

3. Receiver in OBC is failed.

Healing Condition

Disconnect the gun and connect back after VCU sleep

Write up for

the

ystem:-

LV supply of OBC is from 12V battery. It requires AC High voltage supply voltage of 230V, 50Hz to charge the HV battery.

The control pilot (CP) signal has two functions. First is to submit the maximum allowed input current from the

charging station to the vehicle, second is to monitor the proper ground connection between car and charging station

Pre-Check Points:

a) Check for proper rated charging gun

TroubleShooting:-

Flow Diagram or table format for diagnosing the fault code

Step no

Description

Check Point

if YES

if NO

Connect the Charging Gun & switch ON

the AC supply. check for the fault code.

Fault code P229003

is present?

Go to step 2

Repair complete.

Change the Charging Gun

Fault code P229003

is present?

Replace the OBC.

Replace the gun and

repair complete.

DTC

’

confirmation:-

On-Board charger

230V AC supply

HV Battery

LV signal connector
