6. Loosen and remove three door latch mounting
screws.
7. Disconnect the link between lock barrel and
latch from the lock barrel end.
8. Disconnect the outer handle link from the outer
handle end.
9. Remove the door latch.
FITMENT
For fitment follow reverse procedure of removal.
4.13. FRONT DOOR GLASS AND WINDOW
WINDING MECHANISM
REMOVAL
1. Before starting to remove first lower the window
glass.
2. Remove the door trim.
(For procedure refer
door trim removal procedure.)
3. Open the front door and loosen and remove
mounting screw of the outer belt.
4. Remove the outer
belt
of door window.
5. Loosen the window winding mountings.
